A miniature magnetic-sensing prototype and fluid channel beside a ruler.
NIST · US federal public domain
Components · Unspecified

NIST NMR-on-a-chip prototype

A prototype combines a miniature atomic magnetometer with a fluid channel for small-sample measurements. Archival NIST photograph from 2008.

Organization
NIST
Image type
Photograph
Capture date
2008-02-19

Archival photograph. Capture date 2008-02-19 is established by the source; no timezone supplied.

Photographer / creator
NIST
Reuse terms
US federal public domain

NIST · US federal public domain

Full-frame photograph rendition extracted from the supplied atlas, proportionally resized and converted to WebP. No crop, retouching or generated elements.
