Microscope view of a large spiral circuit connected to two smaller drum structures.
NIST · NIST public information reuse terms
Micrographs · Unspecified

Quantum drums - wide microscope view

A microscope image of two mechanical drums and their associated circuit, released by NIST. Source uploaded June 2023; photograph date is not established.

Organization
NIST
Image type
Device micrograph
Capture date
Not supplied by source

Archival microscope image. Capture date is not established; source uploaded June 2023.

Photographer / creator
NIST
Reuse terms
NIST public information reuse terms

NIST · NIST public information reuse terms

Proportional resizing and WebP re-encoding. No crop, compositing, recoloring or content removal. Original source and license retained.
