NIST ultrahigh vacuum (UHV) STM

NIST’s ultrahigh-vacuum scanning probe microscope platform. Source uploaded September 2024; this is measurement infrastructure, not a quantum processor.

Organization
NIST
Image type
Photograph
Capture date
Not supplied by source

Archival photograph. Capture date is not established; source upload dates are not camera timestamps.

Photographer / creator
NIST
Reuse terms
NIST public information reuse terms

NIST · NIST public information reuse terms

Proportional resizing and WebP re-encoding. No crop, compositing, recoloring or content removal. Original source and license retained.
