A small green-and-gold superconducting detector chip lying on a pale surface.
Verma/NIST · NIST public information reuse terms
Components · Photonic

Single-Photon Detector - NIST chip

A NIST superconducting nanowire single-photon detector chip. Archival photograph created September 15, 2014.

Organization
NIST
Image type
Photograph
Capture date
2014-09-15

Archival photograph. The capture date is identified by the source.

Photographer / creator
Verma/NIST
Reuse terms
NIST public information reuse terms

Verma/NIST · NIST public information reuse terms

Proportional resizing and WebP re-encoding. No crop, compositing, recoloring or content removal. Original source and license retained.
